  1. Penjelasan Sequence Diagram Data
  2. Penjelasan Sequence Diagram Dan
Penjelasan Sequence DiagramPenjelasan sequence diagram dan

Penjelasan Sequence Diagram Data

Notation DescriptionVisual Representation

Actor

  • a type of role played by an entity that interacts with the subject (e.g., by exchanging signals and data)
  • external to the subject (i.e., in the sense that an instance of an actor is not a part of the instance of its corresponding subject).
  • represent roles played by human users, external hardware, or other subjects.

Note that:

  • An actor does not necessarily represent a specific physical entity but merely a particular role of some entity
  • A person may play the role of several different actors and, conversely, a given actor may be played by multiple different person.

Lifeline

  • A lifeline represents an individual participant in the Interaction.

Activations

  • A thin rectangle on a lifeline) represents the period during which an element is performing an operation.
  • The top and the bottom of the of the rectangle are aligned with the initiation and the completion time respectively

Call Message

  • A message defines a particular communication between Lifelines of an Interaction.
  • Call message is a kind of message that represents an invocation of operation of target lifeline.

Return Message

  • A message defines a particular communication between Lifelines of an Interaction.
  • Return message is a kind of message that represents the pass of information back to the caller of a corresponded former message.

Self Message

  • A message defines a particular communication between Lifelines of an Interaction.
  • Self message is a kind of message that represents the invocation of message of the same lifeline.

Recursive Message

  • A message defines a particular communication between Lifelines of an Interaction.
  • Recursive message is a kind of message that represents the invocation of message of the same lifeline. It's target points to an activation on top of the activation where the message was invoked from.

Create Message

  • A message defines a particular communication between Lifelines of an Interaction.
  • Create message is a kind of message that represents the instantiation of (target) lifeline.

Destroy Message

  • A message defines a particular communication between Lifelines of an Interaction.
  • Destroy message is a kind of message that represents the request of destroying the lifecycle of target lifeline.

Duration Message

  • A message defines a particular communication between Lifelines of an Interaction.
  • Duration message shows the distance between two time instants for a message invocation.

Note

A note (comment) gives the ability to attach various remarks to elements. A comment carries no semantic force, but may contain information that is useful to a modeler.

Penjelasan Sequence Diagram Dan

Manipulation Language) diagram meliputi use case diagram, activity diagram, Sequence diagram, class diagram, desain database, arsitektur sistem, rancangan interface, dan rancangan format pesan dari data request. Pada analisa sistem terdapat dua hal yang dibahas yakni kebutuhan fungsional dan kebutuhan non fungsional. Diagram ini menunjukan interaksi berdasarkan urutan, dengan kata lain Sequence Diagram ini menunjukan sesuatu urutasn peristiwa. Selain itu Sequence Diagram digunakan oleh pengembang dan profesional bisnis untuk mendokumentasikan proses atau memahami persyaratan pada sistem atau program baru. Berikut adalah komponen-komponen dari Sequence Diagram. Diagram Urutan (Sequence Diagram) Sequence Diagram menggambarkan kelakuan objek pada use case dengan mendeskripsikan waktu hidup objek dan pesan yang dikirimkan dan diterima antar objek. Simbol-simbol yang digunakan dalam Sequence Diagram yaitu: Tabel 3 Sequence Diagram Gambar Keterangan Entity Class, merupakan bagian dari.
